Features and Benefits

·        Wall mounted

·        Built-in transient voltage protection

·        UPS Eco-Mode compatible

·        Safe asynchronous source transfers

·        Very high MTBF (>800,000 hours)

·        LED mimic decal with graphic OLED interface

·        One touch transfers

·        Visual and sound alarm

·        Integrated web server

·        Remote operation

·        High-level interface - MODBUS, SNMP

·        Email alerts

·        Clock synchronisation with NTP

·        Incoming source isolator switches

·        Integrated maintenance bypass with hot socket field replaceable power module

·        Fixed wiring to input & output terminals for cable up to 70mm²

·        5 x Voltage free contacts & remote inputs

·        Australian designed & manufactured

Specifications

·        1-Phase/2-Pole or 3-Phase/3-Pole or 3-Phase/4-Pole – 3Ph models are 4-wire + earth unless otherwise stated

·        Current rating 63A to 160A

·        Voltage rating All region-specific voltages selectable ±10%

·        Safe install environment 20kA, 300A internally fused

·        Frequency 50Hz and 60Hz, ±10% - Auto detect

·        Transfer at zero current by break-before-make by Thyristors / SCR

·        Protection 300A fuses – aR-NGT00

·        RS232 or RS485 with third party adapter
